88E European louvers

Product Introduction:

European shade shutter is a very modern shade product. The product is simple in appearance, with the lighting roof and aluminum glass curtain wall, can fully reflect the modern architectural style. The blade of the product can be turned over to adjust the Angle, integrating the functions of louver and canopy curtain, with dimming, shading, heat preservation, heat insulation and other functions. European louvers are widely used for shading and heat insulation on the top surface of glass buildings and external walls. They can be installed horizontally, vertically and on inclined planes, and are suitable for shading on various public building planes, facades and inclined planes.

Size limitation:

500mm ≤ Width ≤ 3000mm

500mm ≤ Length ≤ 4000mm

*(Using different product configurations, the size will vary)


Product characteristics

Fitting parameter

Control mode

Relevant case

Recommended product

Product characteristics



· The blade can not be folded, and the Angle can be adjusted arbitrarily in the range of 0-90° to control the indoor light


· Single-layer aluminum alloy blade, blade width of 88mm, thin and delicate blade, flexible adjustment of light, more uniform light


· This mechanism has excellent weather resistance, corrosion resistance and wind resistance


· Irregular surfaces such as triangles and trapezoids can also be installed


· Local switch, remote control, computer and more intelligent control methods can be realized


· Multiple sets can achieve single control, group control or group control


· Color and profile can be customized according to demand



Fitting parameter

ColourRegular color: oxidized, brown, dark gray; Special colors: Customizable
MaterialAluminum alloy material
DimensionLength: 1M≤L≤8M Width: 1M≤W≤2.5M
Surface treatmentPowder spraying, anodizing, electrophoresis, fluorocarbon spraying
Blade width108mm
Motor combinationImported, domestic can be matched



Control mode

    - Wireless remote control

    - Infrared remote control

    - Manual control and intelligent control

    - Intelligent control systems such as sunlight, rain and wind sensors are used outdoors to make the shading system more intelligent, convenient and safe


Relevant case
